Acousto-optical quartz (SiO2) Q-switches
Print this frame


Operating frequency and active aperture are available according to customers specifications.
Item Units MT-3203 MT-3204 MT-3205 custom made
  Wavelength nm 755 nm 1660 nm 2130 nm please specify
  Input Optical Aperture mm 3 x 10 3 x 10 3 x 10 please specify
  Light beam divergence mrad < 5 < 5 < 5 -
  Operating frequency MHz 50 50 50 please specify
  Polarisation - Arbitrary Arbitrary Arbitrary -
  VSWR - 1.2 : 1 1.2 : 1 1.2 : 1 -
  Dynamic insertion loss per pass (25 W RF)
% 70 70 70 -
  Heat exchanger
 - stainless steel stainless steel stainless steel please specify
  AR-Coating reflectivity, per suface % 0.1 0.1 0.1 -
  Damage threshold MW/cm2 500 500 500 -
  VSWR - 1.2 : 1 1.2 : 1 1.2 : 1 -
 - Drivers are available -
   I am interested in pcs of:
This field is for additional information such as application, comments, etc.
Requirements for the custom made device:
Your company name and address:
Name:
Tel-No:
Fax:
E-Mail:

for passive Q-switches (Cr+4:YAG, GSGG:Mg,Cr4+, V3+:YAG, Co+2:MgAl2O4 (Spinel), NANO-CRYSTALS IN CERAMICS) please follow this link
